| BRAND | Burkert |
| Product | 00328852 |
| Internal code | IMP5043667 |
| Weight | 3.3 |
| Technical specification | 2-way angle seat control valve pneum. 2300-A2-25,0SS-VASA44-G-N-ABN3-FA03 NK51+PL01+PX51 Control function A Closed with spring force Ways/positions 2 2 ways/2 positions Nominal size 25.0 25 mm SS stainless steel sealing material Material VA stainless steel SA44 welding cable connection 33.7 x 2.0 in accordance with ISO 4200, DIN EN ISO 1127, DIN 11866 series B Drive Type G Element Design Drive Drive size N DM 90 mm Interface on drive AB Sitzv, SP 14, drive 90; thread 73 x 3 Arm interface. /Drive N3 nipple thread M40 x 1.5 (standard DN 25) Control air connection FA03 Interface element control and remote sensor to element drive Special feature NK51 Packaged seal included PL01 suitable for use with foodstuffs, materials in contact with media are compliant with EC Regulation 1935/2004 in accordance with manufacturer's declaration PX51 EPS 18 ATEX 2008 X/IECEx EPS 18.0007 X mech. ex h IIC T4... T2 Gb/Ex h IIIC T135°C... T300°C Db Pressure min 0 bar Pressure max 25 bar Control pressure min 5.50 bar Control pressure max 7 bar KV 16 m3/h Medium temperature min -10 °C Medium temperature max 185 °C Ambient temperature min -10 °C Ambient temperature max 100 °C |
Discover the superior quality and performance of the Burkert 00328852 with Impexron GMBH in Australia. Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 00328852 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 00328852:
At Impexron GMBH, we offer the 00328852 at competitive prices and with the fastest delivery times across Australia. Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the 00328852? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Australia, offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Australia, we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
2/2-way solenoid valve; direct acting
valve, 2 type:2000, DN 20, Stainless, Piston diameter 40 mm
valve, 3 type:2000, DN 32, Stainless, Piston diameter 63 mm
2/2-way piston control angle seat valve
valve, 3 type:2000, DN 25, Stainless, Piston diameter 50 mm
valve, 1 type:2000, DN 15, Stainless, Piston diameter40mm
Valve positions
1M IMMERSION FITING MONTAGE-KIT TIP.KOMPAKT
1M IMMUNITY FITTING - KIT TIP: COMPACT including cable and flange
PVDF BODY
2/2-WEGE-FLIPPERVENTIL 10MM GP
Type 6124 6124 Function A 2/2-way; Normally closed Nominal size 00,6 0,6 mm Seal material FKM FF Material PK PEEK Line connection flange FB08: 10 X 18mm 6603/6604 Coil size 0 Type Based specified Voltage 024 volts 24 Frequency BA battery power Power consumption 1.5 watt AC Special JF80 mm rectangular connector 5:08, 2-pole Pressure range -1 - 3 bar Pressure max / gas 3 bar Weight: kg / St 0.015
2/2-WEGE-FLIPPERVENTIL 10MM GP 00144120
Type 6124 6124 Function A 2/2-way; Normally closed Nominal size 00,6 0,6 mm Seal material FKM FF Material PK PEEK Line connection flange FB08: 10 X 18mm 6603/6604 Coil size 0 Type Based specified Voltage 012 volts 12 Frequency BA battery power Power consumption 1.5 watt AC Special JF80 mm rectangular connector 5:08, 2-pole Pressure range -1 - 3 bar Pressure max / gas 3 bar Weight: kg / St 0.015
2/2-WEGE-MAGNETVENTIL, DIREKTWIRKEND
(Type 0255)
2/2-way piston control angle seat valve
gasket kit
35gradusa 11bar CM25
½ PMed Pilot 5-10b diaphragm membrane 10b for valves 15 (DN 15) EPDM
00141576 W33LP
valve D13.5 Pmax 10bar Pilote 4.7 bar MiCR 191930J,THE FOLLOWING PARTS, THE SPRINGS AND MEMBRANE DN8 EPDM
2/2 way solenoid valve
positively controlled 2/2-way solenoid valve, Type 6213 6213 generation EV Function A 2/2-way; Normally closed nominal diameter 25.0 mm 25 Seal material FKM FF Material Stainless steel VA GM86 line connection socket G 1 Coil size L 65 mm Voltage 024 volts 24 Frequency DC DC Power 28 28 Watt Special NA38 coil for higher temperatures Pressure range 0 - 10 bar
PH METER
