BRAND | Tecsis (WIKA Group) |
Product | 13261274 |
Internal code | IMP3934283 |
Technical specification | Pressure transmitter for general applications Model S-11 with flush diaphragm Specifications according to data sheet: PE 81.02 Power supply: DC 10 (14) ... 30 V Case: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 0.25 bar Process connection: G 1 B flush diaphragm with O-ring Wetted parts: stainless steel Sealing: FPM/FKM Accuracy: 0.5% of span Electrical connection: circular connector M12x1, 4-pin Permissible medium temperature: -20 ... +150 °C (-4 ... +302 °F) Power supply: 10 ... 30 V DC Pin assignment: U+=1, U-=3 |
Please Contact Us to Order to offer competitive prices and delivery time for Tecsis (WIKA Group) - 13261274 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
