170M6169 - BUSSMANN / EATON Australia Sales

BRAND	BUSSMANN / EATON
Product	170M6169
Description	Fuse-link
Internal code	IMP1861664
Weight	0.5
Custom code	85361090
Technical specification	high speed, 1600 A, AC 690 V, DIN 3, 76 x 90 x 139 mm, aR, DIN, IEC, single indicator INTERRUPT RATING 200 kAIC CLEARING LOSS 160 CENTER-TO-CENTER DISTANCE OF CONNECTIONS 108 mm INSULATED METAL GRIPPING LUGS (IMGL) No CURRENT TYPE AC AMPERAGE RATING 1600 A FUSE TYPE DIN 43653 /110 Visual indicator FUSE SIZE 3 VOLTAGE RATING 690 V (IEC), 700 V (UL) FUSE INDICATOR Top fuse status indicator CONSTRUCTION SIZE 3 CLEARING (I2T) 3900000 at 660 V RATED VOLTAGE AC 690 V COLOR None CONNECTION Blade end x blade end MOUNTING DIMENSION Other UTILIZATION CATEGORY aR (accompanied semiconductor protection) WATT LOSSES 160 W TYPE Fuse FUSE SHAPE Square body, slotted center bolted tags BREAKING CAPACITY 200 kA CLASS Class aR PRE ARC (I2T) 580000 APPLICATION Semiconductor, DC Common bus, DC drives, power converters/rectifiers VOLTAGE TYPE AC

Please Contact Us to Order to offer competitive prices and delivery time for BUSSMANN / EATON - 170M6169 Fuse-link number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
