| BRAND | Stahl |
| Product | 220322 / 9160/23-11-11s |
| Description | Transmitter power supply unit |
| Internal code | IMP4457641 |
| Custom code | 85363010 |
| Technical specification | max. voltage Uo: 27 V Max. current Io: 88 mA Max. power Po: 576 mW Max. voltage Ui: 30 V Max. current Ii: 100 mA Nominal current: 148 mA Power consumption: 3.4 W Number of channels: 2 Connection type: screw terminal input: 0/4... 20 mA with HART output A: 0/4... 20 mA LFD relay: Yes SIL: 2 Min. ambient temperature: -20 °C Max. ambient temperature: +70 °C Application area (zones): 2 Gas explosion protection: II 3 (1) G Ex nA nC [ia Ga] IIC T4 Gc Dust explosion protection: II (1) D [Ex ia Da] |
Please Contact Us to Order to offer competitive prices and delivery time for Stahl - 220322 / 9160/23-11-11s Transmitter power supply unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
