BRAND | Südmo |
Product | P/N: 2324362 Type: A372-D-EAF |
Description | asept. cross valve |
Internal code | IMP4464301 |
Custom code | 84818073 |
Technical specification | Design: cuff/O-ring Nominal size: OD 0.50" Working method: air-opening-spring-closing for use as an overflow valve with adjustable spring force Setting range: 3.0-12.0 bar Response pressure: ____ bar : with US lantern housings Connection: 4x welding end : A-B Ø 12.70 x 1.65 : C-E Ø 12.70 x 1.65 Seal: P3 cuff/FKM Approvals: FDA Material: 1.4404 (AISI 316L) Surface: Ra <= 0.8 μm Valve is in accordance with the Pressure Equipment Directive 2014/68/EU not as a piece of equipment with safety function can be used and therefore also has no component testing according to 2014/68/EU. Setting pressure: 9 bar |
Please Contact Us to Order to offer competitive prices and delivery time for Südmo - P/N: 2324362 Type: A372-D-EAF asept. cross valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
