BRAND | Scherzinger |
Product | 3030-110-PK |
Description | Pump |
Internal code | IMP4849555 |
Custom code | 84136039 |
Technical specification | specifications • Explosion protection: 2014/34/EU - II 2GD cX • Preferred direction of rotation: left (ccw), view of the pump shaft • Discharge volume: 1.1 cm³/U • Connections: DIN ISO 228, G 1/4" • Permit pump inlet pressure: -0.9... 89 bar • Operating temperature range: -20 to 130°C Construction materials • Housing material: 1.4404 • Gear material: PEEK mod. • Waves: 1.4571 • Bearings: PEEK mod. • stat. Seals: PTFE • Shaft seal: • max.0.65 Nm • Sm2Co17 magnets, encapsulated in 1.4404 pumphead • with split cup and pump-side magnetic coupling hub • including centering ring, with screw holes Important notes • Please install a coarse filter with a mesh size of 50 µm in front of the pump • Pump not suitable for liquids with magnetic particles • Pump not suitable for particulate media • According to ISO 4406, the purity class of the medium should be at least 19/17/14 |
Please Contact Us to Order to offer competitive prices and delivery time for Scherzinger - 3030-110-PK Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
