3030-110-PK - Scherzinger Australia Sales

BRAND	Scherzinger
Product	3030-110-PK
Description	Pump
Internal code	IMP4849555
Custom code	84136039
Technical specification	specifications • Explosion protection: 2014/34/EU - II 2GD cX • Preferred direction of rotation: left (ccw), view of the pump shaft • Discharge volume: 1.1 cm³/U • Connections: DIN ISO 228, G 1/4" • Permit pump inlet pressure: -0.9... 89 bar • Operating temperature range: -20 to 130°C Construction materials • Housing material: 1.4404 • Gear material: PEEK mod. • Waves: 1.4571 • Bearings: PEEK mod. • stat. Seals: PTFE • Shaft seal: • max.0.65 Nm • Sm2Co17 magnets, encapsulated in 1.4404 pumphead • with split cup and pump-side magnetic coupling hub • including centering ring, with screw holes Important notes • Please install a coarse filter with a mesh size of 50 µm in front of the pump • Pump not suitable for liquids with magnetic particles • Pump not suitable for particulate media • According to ISO 4406, the purity class of the medium should be at least 19/17/14

Please Contact Us to Order to offer competitive prices and delivery time for Scherzinger - 3030-110-PK Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
