481500W232A1EL1 A40UKM0 - Gemü Australia Sales

BRAND	Gemü
Product	481500W232A1EL1 A40UKM0
Internal code	IMP4475249
Custom code	84818085
Technical specification	Type 481 butterfly valve, pneumatically operated victoria DN 500 DN 500 housing form W intermediate flange version (wafer), Length AGV EN 558 series 20 Operating pressure: 2, 10 bar Connection type 3 PN 16/ flange EN 1092, installation length FTF EN 558 series 20 Housing material 2 EN-GJS-400-15 (GGG-40), epoxy coated 250 μm Material disc A 1.4408 Material shaft 1 1.4021 Shut-off seal material E EPDM Cuff fixation L seat ring loose Control function 1 Closed in rest position (NC) Drive version A40UKM actuator, pneumatic, single-acting, clockwise, spring-closing, ASR4000US14F16/25 S55 Special features Drive 0 General industrial version, aluminium housing, anodized layer 25-35μm, aluminium end caps, powder-coated, Carbon steel+ENP shaft, A2 screws

Please Contact Us to Order to offer competitive prices and delivery time for Gemü - 481500W232A1EL1 A40UKM0 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
