BRAND | FSG Fernsteuergeräte |
Product | 5875Z01-016.018 Typ: MH1023-MU/Ex |
Internal code | IMP4450221 |
Custom code | 90318020 |
Technical specification | Intrinsically safe angle encoder in ATEX approval PTZ 17 ATEX 0001 and IECEx approval IECEx KIWA 17.0010/PTZ 18,0004 temperature class T4 in synchronous size 23 housing Protection class IP 66 stainless steel flange and casing cap Max. angle measurement range 0 - 360° Resolution: 14bit/360° output: 4 - 20 mA max. burden: (us-8V) /20mA Output: 2-wire technology Active angle and direction of rotation via back Polymembrane keyboard programmable power supply: 8-26V DC temperature range -30°C to +80°C electrical connection via shielded cable length 25 m shaft diameter 10 mm, length 24 mm from pad with shaft seal ED103-0066 |
Please Contact Us to Order to offer competitive prices and delivery time for FSG Fernsteuergeräte - 5875Z01-016.018 Typ: MH1023-MU/Ex number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
