70590533 - Demag Australia Sales

BRAND	Demag
Product	70590533
Internal code	IMP3400274
Weight	107.2
Custom code	85030099
Technical specification	LIFTING MOTOR SET ZBR132D12/2V1 Product details Part no. 70590533 customs tariff 85030099 product group ropehoist model range DR size 10 net weight 107,2 kg PUG 5137 Included parts (44) Item Product Units 1 End shield ZBR132 DR5/10 1 EA 2 End shield B140 ZBR132 1 EA 3 Rotor ZBR132D12/2 Iko 1 EA 4 Fan cover long ZB132 1 EA 5 Mounting parts ZB132-B140 1 EA 6 Terminal box cover Z132 -225 1 EA 7 Stator connection ZBR132 1 EA 8 Grooved ball bearing 6209 2Z HTF2 1 EA 9 Retaining ring 85X3 1 EA 10 Grooved ball bearing 6207 2Z HTF2 1 EA 11 Fan impeller light Z 132 1 EA 12 Oil seal A 45X 62X 7 1 EA 13 Cover disk 45X62X4,5RB45 1 EA 14 Magnet body B140 180V 1 EA 15 Stop disk B140 1 EA 16 Damping plate B140 1 EA 17 Collar pin B140 A2-70 MK 3 EA 18 Anchor plate G/B140 1 EA 19 Engaging element B140-ZB132 1 EA 20 O-ring 60 X 2,5 N 1 EA 21 Washer 12 special 3 EA 22 Spring brake Weiss B140 6 EA 23 Spring spacing B140 3 EA 24 Masking tape B140 1 EA 25 Brake disk FB1121 1 EA 26 Stud micro-switch 1 EA 27 Holder parts microswitch 1 EA 28 Microswitch V4NOS 1 EA 29 Oil seal AS 30X 52X 7 1 EA 30 Stator ZBR132D 12/2 1 EA 31 Pulse wheel EG Z132 1 EA 32 Unit IMP RS422 10-30V 1 EA 33 Built-in pulse encoder EG/Z132 1 EA 34 Supporting plate 30X 52X0,5 1 EA 35 Terminal block module ZBR 1 EA 36 Mounting plate ZBR100/132 1 EA 37 VDR resistor insulated 1 EA 38 VDR resistor 401-500V 1 EA 39 Rating plate LAYOUT USA 1 EA 40 Patch cord ZBR132D2/12 1 EA 41 Motor interfer.suppression RC-3 1 EA 42 Plug-in pinion Z 11 M2 B 44 1 EA 43 Gearbox seal A50/A60 1 EA 44 Lock nut M12 VB.RIPP 4 EA

Please Contact Us to Order to offer competitive prices and delivery time for Demag - 70590533 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
