BRAND	Stahl
Product	p/n: 285669, Type: 8146/5061
Description	control box
Internal code	IMP4324972
Custom code	85371098
Technical specification	type key: 8146/5061 Explosion protection gas ATEX: II 2 G Ex db eb IIC T4 Gb Explosion protection dust ATEX: II 2 D Ex tb IIIC T130 °C Db Explosion protection gas IECEX: Ex db eb IIC T4 Gb Explosion protection dust IECEX: Ex tb IIIC T130 °C Db Document number ATEX: PTB01ATEX1024 Document number IECEX: IECEXPTB060090 Degree of protection (IP): IP66 Ambient temperature: -20 °C... +60 °C Temperature class: T4 Rated voltage [UN]: 230V Rated current: 6A Frequency: 50/60Hz Section: 4/2.5mm2 Type plate material: polyester film Wiring: no 1 piece 8146/-061 Empty housing, polyester resin, 227mm x 170mm x 91mm 1 piece 8602A3-023-B Double push button Polyamide, silicone-free 1 piece 8602/3 Button label, green, START 1 piece 8602/3 Button sign, red, STOP 1 piece 8082A0060-1-0, contact element, 1 NC + 1 NO contact Contact material: silver-nickel 1 pc 8602A3-731-B-90G-E99 Rotary handle large, black - black Polyamide, silicone-free 1 piece 8602/3 Sign unmarked, Ø 58 mm 1 piece 8008/2-016 Control switch, number of poles: 2 Contact material: silver-nickel 4 hours UT 4 Terminal block, gray, 4 mm2 2 pcs USLKG 5 GNYE Protective conductor terminal, green-yellow, 4 mm2 3 pieces 8290/3-M20 Sealing plug M20, polyamide Configuration ID 00000000002017659665

Please Contact Us to Order to offer competitive prices and delivery time for Stahl - p/n: 285669, Type: 8146/5061 control box number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
