CTD2X3005AXXX - Carlo Gavazzi Australia Sales

BRAND	Carlo Gavazzi
Product	CTD2X3005AXXX
Description	AC Current Transformer
Internal code	IMP241853
Weight	1
Technical specification	AC Current Transformer (max 30x10mmbus-bar) Type CTD-2X • Bus-bar type current transformer • 0.5 class, currents from 40 to 600 A • Integrated DIN-rail mounting holder • Removable panel fixing clips • 2 Bus-bar isolated fixing screws • Double screw terminals (up to 8-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-2X 200 5A XXX Cable/Bus-bar type current transformerwith DIN-rail/bus- bar and panel mounting facili- Type Selection ty. Rated primary currents from 40 A to 600 A. Model Primary current Secondary current Option Optional fixing kit: CTD-kit Primary current From 40 to 600A (Refer to Range Table) Input Specifications Secondary current 1A 5A Option XXX:none XTX:tropicalization Operating frequency45 to 65 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class E (max 75°C) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-time thermal current Ith is anyway limited by the cable/ bus-bar size Extended current rating 120% Security factor (FS)≤ 5 (Class: 0.5, 1 and 3) General Specifications Standards According to EN60044-1 HousingABS, self-extinguishing: UL 94 V-0 MountingDIN-rail bus-bar and panelmounting Standard accessoriesTwo terminal blockscrews. Two cable/bus-bar fixingscrews. Two sealable terminal block covers. Two panelmounting fixingclips. Two plastic caps for cable/bus-bar fixingscrews. Optional accessoriesExtended fixing kit: CTD-kit Two panel mounting fixing clips. Six cable/bus-bar fixing screws. Six plastic caps for cable/bus-bar fixing screws. Special features 1 A secondary current, Tropicalization Working temperature-25°Cto +60°C (-13°F to 140°F) (R.H.< 90% non condensing @ 40°C) Storage temperature -30°Cto +70°C (-22°F to 158°F) (R.H.< 90% non condensing @ 40°C) Approvals CE, cUrus and CSA Connection Screw type Cablecrosssection areaFrom1.5 to 6 mm2 Min/Max screws tightening torque relevant to terminal blockscrews: From1 to 2 Nm Max screws tightening torque relevant to the cable/bus-bar fixingscrews: 0,3 Nm Protection degreeIP00 IP20(withsealable terminal block covers + wire terminals) Cablediameter Max. 24 mm Bus-bar size HorizontalMax. 32x5 30x10 25x20 mm Vertical Max. 25x12mm Weight From350 to 500 g Output Specifications Rated secondary current5 A or 1 A

Please Contact Us to Order to offer competitive prices and delivery time for Carlo Gavazzi - CTD2X3005AXXX AC Current Transformer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
