BRAND | Gemü |
Product | D487150W3D2A1EL0 DAHL14 |
Internal code | IMP4858158 |
Custom code | 8481 8085 |
Technical specification | Type D487 butterfly valve, manually operated DN 150 DN 150 Housing shape W intermediate flange design (wafer), FTF EN 558 series 20 series length Operating pressure 3 16 bar Connection type D ANSI B16.5, class 150, construction length FTF EN 558 series 20, For LUG housing/threaded holes, UNC threads Housing material 2 EN-GJS-400-15 (GGG-40), epoxy coated 120 µm Disc material A 1.4408 Shaft 1 material AISI 420/1.4021 E EPDM barrier seal material Cuff fixation L seat ring loose Control function 0 Manually operated DAHL14 drive version, aluminium hand lever The following documentation is part of the order item Documents are available in the customer portal 2.1 Factory certificate 2.2 Work certificate for operability |
Please Contact Us to Order to offer competitive prices and delivery time for Gemü - D487150W3D2A1EL0 DAHL14 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
