BRAND | Merkle |
Product | DHZ 160.50/28.02.208.140 AA11.EE44.DD02 / 115060 |
Description | AHP hydraulic cylinder |
Internal code | IMP4639888 |
Custom code | 84122180 |
Technical specification | Drawing number 13.54415.02 Type DIN cylinder 160bar cylinder type designation DHZ 160 piston diameter 50 mm rod diameter 28 mm Design 02 = rectangular flange front Function 208 = double acting with rear end position cushioning stroke 140 mm Ventilation EE44 = bleed screw on the head and bottom side to position 4 Pos. damping DD02= damping screw on bottom side to position 2 Connection changed AA11 = pipe thread connection head and bottom side to position 1 max. operating pressure 160 ba |
Please Contact Us to Order to offer competitive prices and delivery time for Merkle - DHZ 160.50/28.02.208.140 AA11.EE44.DD02 / 115060 AHP hydraulic cylinder number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
