MOC3021-M - Fairchild Australia Sales

BRAND	Fairchild
Product	MOC3021-M
Description	Photocouplers
Internal code	IMP531583
Weight	1
Technical specification	Self-propelled: No PPAP: No Number of channels per chip: 1 Zero-cross circuit: No Maximum ignition time (us): 20 Standard: CSA\|FIMKO\|UL Output device: Triac Output type: AC Maximum Output Voltage (VAC): 280 Minimum insulation voltage (Vrms): 5000 Typical Direct Voltage (V): 1.15 Maximum direct voltage (V): 1.5 Repetitive off-state peak voltage (V): 400 Maximum reverse voltage (V): 6 Typical critical rate of off-state voltage increase (V/us): 100 (minimum) Maximum direct current (mA): 50 Minimum trigger current (mA): 8 (typical) Repetitive maximum off-state current (uA): 0.1 Maximum Power Dissipation (mW): 330 Minimum operating temperature (°C): -40 Maximum Operating Temperature (°C): 100 Mounting: Through the hole Package height: 3.5 Package Width: 6.5 Package Length: 7.3 PCB changed: 6 Standard package name: SALSA Vendor package: PDIP Number of pins: 6 Shape of lead: Through the hole

Please Contact Us to Order to offer competitive prices and delivery time for Fairchild - MOC3021-M Photocouplers number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
