| BRAND | Hengesbach |
| Product | VRM100_10bar_K |
| Description | pressure transmitter |
| Internal code | IMP4278608 |
| Custom code | 90262020 |
| Technical specification | p-vrm100nre1k_10bar - Highly overload resistant - With on-site display and operating module. Front flush stainless steel membrane, laser welded, piezoresistive Ceramic based measuring cell Box housing made of fabric 1.4301 Hygienic Design Electronics encapsulated, protection class IP 67 & IP 69K acc. to EN 60529 Supply voltage 13... 36V DC Output signal 4-20 mA, 2-wire, turnDown 10 Linearity ± 0.15% FS Overload protection 1.5 times sensor measuring range Process connection: EHEDG type EL Class 1 certified Modular system PZM with pressure screw, material Wkst. 1.4404/1.4435. /* Incl. O-ring seal 28x2.5, material EPDM (FDA compliant) */ Sensor measuring range/set measuring range: 40 bar, 10 bar, rel Electrical connection: cable gland M16x1.5 According to the data sheet PN-PZM-VRM100-101... in the current version. |
Please Contact Us to Order to offer competitive prices and delivery time for Hengesbach - VRM100_10bar_K pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
