BRAND | Loreme |
Product | RPL23 |
Description | AC or DC protection relay |
Internal code | IMP4003011 |
Custom code | 90308930 |
Technical specification | Mounting - DIN rail: 23 x 100 x 120 mm (plug-in connection) Function - Single-phase or three-phase voltage monitoring with or without neutral cable - Undervoltage detection (or phase absent) - Over voltage detection - Phase order detection (Po option) Input - 50 Vac to 800Vacmaxi Parameter setting - monitoring any nominal voltage from 50 to 700Vac - detection threshold (over or under voltage) - detection delay Relays - 2 potential free changeover relay outputs (5A / 250V) (for threshold detection) Power supply - 20 to 265 Vac / dc Insulation - power supply / input / output 2500 Vac Parameter setting - on the front panel |
Please Contact Us to Order to offer competitive prices and delivery time for Loreme - RPL23 AC or DC protection relay number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Australia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
